| PERFORMANCE | |
|---|---|
| Display Size | 23.8“ |
| View Area | 526.8x296.4 mm |
| Panel | In-Plane Switching |
| Backlight | WLED |
| Aspect Ratio | 16:9 |
| Resolution | 2560x1440 |
| Pixel Pitch | 0.2058x0.2058 mm |
| Dot / Pixel Per Inch | 123 dpi |
| View Angle (H / V) | 178° / 178° |
| Response Time | 4ms GtG (Extreme mode) / 6ms GtG (Typical mode) |
| Color Support | 16.7 Million |
| Refresh Rate | 48Hz - 120Hz |
| Brightness | 300 cd/m² |
| Contrast Ratio | 1500:1 |
| Color Gamut | 99% sRGB, 99% BT.709 |
| Screen Surface Treatment | Anti-glare |
| Curvature | Flat Panel |
| Camera | Modular Camera Support |
| Microphone | None |
| Speakers | Modular Speaker Support |
| Power Consumption (Typical / Maximum) | 12W / 65W |
| Power Adapter | Integrated |
| DESIGN | |
| Stand | Tilt, Swivel, Pivot, Height Adjust Stand |
| Case Color | Raven Black |
| Side Bezel Width | 2 mm |
| Mounting | Supports VESA mount 100 x 100 mm |
| ThinkCentre M Series Support | Tiny Support |
| Dimensions (WxDxH) | Lowest Position | 539.8 x 190.0 x 350.8 mm (21.25 x 7.48 x 13.81 inches) The system dimensions may vary depending on configurations. |
| Dimensions (WxDxH) | Highest Position | 539.8 x 190.0 x 505.8 mm (21.25 x 7.48 x 19.91 inches) The system dimensions may vary depending on configurations. |
| Dimensions (WxDxH) | Head Only | 539.8 x 45.3 x 315.8 mm (21.25 x 1.78 x 12.43 inches) The system dimensions may vary depending on configurations. |
| Packaging Dimensions (WxDxH) | 730 x 123 x 420 mm (28.74 x 4.84 x 16.54 inches) |
| Weight | Monitor With Stand | 5.1 kg (11.2 lbs) The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model. |
| Weight | Monitor Head Only | 3.0 kg (6.6 lbs) The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model. |
| Packaging Weight | 7.6 kg (16.7 lbs) |
| CONNECTIVITY | |
| USB Port | 1x USB-B (USB 5Gbps, USB upstream), 3x USB-A (USB 5Gbps, 1x BC1.2, USB downstream), 1x USB-C (USB 5Gbps, 15W PD, USB downstream) |
| Video Connector | 1x HDMI 2.1 TMDS, 1x DP 1.4 (HBR2), 1x DP 1.4 Out |
| Network Connectivity | None |
| SERVICE | |
| Base Warranty | 3-year |
| CERTIFICATIONS | |
| Environmental Certification | ENERGY STAR Certified,TCO 10, TCO Edge 2.1, EU Energy Efficiency Level (Level-C), EPEAT Gold, Volatile Organic Compound Certification, RoHS |
| Ergonomic Certification | TÜV Rheinland Eye Comfort 5 Stars, Eyesafe Display 2.0, TÜV Low Blue Light (Hardware solution) |
| Sync Technology | None |
| Special Features | HDR10 Compliance |
| Special Features | Factory Calibration: Avg. Delta E<2 at sRGB |
| Special Features | Lenovo ThinkColour (Lenovo Accessories and Display Manager) Support Lenovo ThinkColour supports Windows 10 11, Mac OS (functions vary across systems). Lenovo Accessories and Display Manager is formerly Lenovo Display Control Center. |
| Special Features | LDFM (Lenovo Display Fleet Manager) |
| Special Features | Multi-sync |
| Special Features | Natural Low Blue Light |
| SOFTWARE | |
| Operating System | Support Windows 10, Windows 11 |
| ACCESSORIES | |
| In the Box | Monitor with stand |
| In the Box | 1x DP 1.4 cable (1.8m) |
| In the Box | 1x HDMI 2.0 cable (1.8m) |
| In the Box | 1x Power cable (1.8m) |
| In the Box | Factory calibration report |
| In the Box | Quick setup guide |
