| PERFORMANCE | |
|---|---|
| Display Size | 27" |
| View Area | 596.7x335.7 mm |
| Panel | In-Plane Switching |
| Backlight | WLED |
| Aspect Ratio | 16:9 |
| Resolution | 3840x2160(2D), 1920x2160(3D) |
| Pixel Pitch | 0.155x0.155 mm |
| Dot / Pixel Per Inch | 163 dpi |
| View Angle (H / V) | 178°/178°(2D), 20°/20°(3D) |
| Response Time | 4ms (Extreme mode) / 6ms (Normal mode) |
| Color Support | 16.7 Million |
| Refresh Rate | 60Hz |
| Brightness | 310 cd/m² |
| Contrast Ratio | 1200:1 |
| Color Gamut | 100% sRGB, 99% Adobe RGB, 99% DCI-P3, 100% BT.709, 83% BT.2020 |
| Screen Surface Treatment | Anti-glare |
| Curvature | None |
| Camera | Modular Camera Support |
| Microphone | None |
| Speakers | 5Wx2 |
| Power Consumption (Typical / Maximum) | 43.8W / 246W |
| Power Adapter | Integrated |
| DESIGN | |
| Stand | Tilt, Swivel, Pivot, Height Adjust Stand |
| Case Color | Raven Black |
| Side Bezel Width | 8 mm |
| Mounting | Supports VESA mount 100 x 100 mm |
| ThinkCentre M Series Support | Tiny, Nano Support |
| Dimensions (WxDxH) | Lowest Position | 614.8 x 222.7 x 413 mm (24.2 x 8.77 x 16.26 inches) The system dimensions may vary depending on configurations. |
| Dimensions (WxDxH) | Highest Position | 614.8 x 222.7 x 568 mm (24.2 x 8.77 x 22.36 inches) The system dimensions may vary depending on configurations. |
| Dimensions (WxDxH) | Head Only | 614.8 x 72.3 x 390 mm (24.2 x 2.85 x 15.35 inches) The system dimensions may vary depending on configurations. |
| Packaging Dimensions (WxDxH) | 720 x 165 x 520 mm (28.35 x 6.5 x 20.47 inches) |
| Weight | Monitor With Stand | 8.9 kg (19.6 lbs) The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model. |
| Weight | Monitor Head Only | 6.6 kg (14.6 lbs) The system weight is approximate and based on results in Lenovo lab, which varies depending on the source of component, variance of the distribution of each component, and manufacturing process. It may not be the exact weight for each specific model. |
| Packaging Weight | 12.4 kg (27.3 lbs) |
| CONNECTIVITY | |
| USB Port | 1x USB-C 3.2 Gen 1 (DP 1.4 Alt Mode, up to 100W PD, USB upstream), 4x USB 3.2 Gen 1, 1x USB-C 3.2 Gen 1 (15W PD) |
| Video Connector | 2x HDMI 2.1 TMDS, 1x DP 1.4, 1x USB-C 3.2 Gen 1 (DP 1.4 Alt Mode) |
| Network Connectivity | 1x RJ45, Ethernet (10M/100M/1000M) |
| SERVICE | |
| Base Warranty | 3-year |
| CERTIFICATIONS | |
| Environmental Certification | RoHS, EU Energy Efficiency Level (Level-G) |
| Ergonomic Certification | TÜV Rheinland Eye Comfort |
| Sync Technology | None |
| Special Features | HDR Compliance (HDR10 Decoding) |
| Special Features | Factory Calibration: Avg. Delta E<1 (for DCI-P3, Adobe RGB and sRGB) |
| Special Features | 3D Explorer, available from Lenovo Accessories and Display Manager (ThinkColour) Lenovo Accessories and Display Manager supports Windows 10 11, Mac OS, and Windows On Arm (functions vary across systems) |
| Special Features | 3D Master (3D viewing App), Design Engine, 2D-to-3D Converter, Plugins, SDK |
| Special Features | Smart Power The Smart Power function intelligently detects overall power consumption and dynamically manages the power delivery to each device |
| 3D Features | 2D/3D Switchable |
| 3D Features | 3D resolution: 1920 x 2160 |
| 3D Features | Environmental conditions: 0 lx - 1000 lx |
| 3D Features | Eye tracking support |
| 3D Features | Number of viewers: 1 |
| 3D Features | Optimal viewing angle: -20° to +20° horizontal, -20° to +20° vertical |
| 3D Features | Optimal viewing distance: 60 - 100 cm |
| 3D Features | Recommended 3D viewing distance: 70 - 90 cm |
| 3D Features | Minimal PC Requirements: CPU: i5 7400/3.00GHz Graphic: NVIDIA GeForce GTX 1050 (or AMD, Intel graphics card with equivalent performance) Operating system: Windows 10 (64-bit) Memory: 8GB DDR5 Storage: 50GB available space |
| 3D Features | Supported third-party software: Microsoft 365, PTC Creo, Autodesk 3ds Max, Autodesk VRED, Autodesk Maya, Trimble SketchUp Pro, Blender, Lumiscaphe Patchwork 3D, Dassault Systems Deltagen, Unity, C++ Unreal (via SDK) |
| SOFTWARE | |
| Operating System | Support Windows 10, Windows 11 |
| ACCESSORIES | |
| In the Box | Monitor with stand |
| In the Box | 1x DP cable (1.8m) |
| In the Box | 1x HDMI cable (1.8m) |
| In the Box | 1x USB-C to USB-A cable (1.8m) |
| In the Box | 1x USB-C to USB-C Gen 2 cable (1.5m) |
| In the Box | 1x Power cable (1.8m) |
| In the Box | 1x Quick setup guide |
| In the Box | Factory calibration report |
| In the Box | Cleaning cloth |
